MF72-0805 Series

Introduce

Offers stable thermistor performance and higher power handling capacity. Ideal for temperature management and surge control in smart home devices, power modules, and consumer electronics.

Inquiry

A^-A⁺

Parameter Inquiry

Part No	Resistance (25℃) (kΩ)	B Constant (25/50℃) (K)	B Constant (25/85℃) (K)	Permissible Operating Current (25℃) (mA)	Dissipation Factor (mW/℃)	Thermal Time Constant (s)	Rated Electric Power (25℃) (mW)	Operating ambient temperature (℃)
JR0805N202F3450FB	2.0	3450	3500	1.0	1.0	<5	200	-40~+125
JR0805N202F3950FB	2.0	3950	3987	1.0
JR0805N222F3450FB	2.0	3450	3500	0.90
JR0805N222F3950FB	2.2	3950	3987	0.90
JR0805N332F3450FB	3.3	3450	3500	0.72
JR0805N332F3950FB	3.3	3950	3987	0.72
JR0805N472F3500FB	4.7	3500	3545	0.65
JR0805N472F3950FB	4.7	3950	3987	0.65
JR0805N50F3950FB	5.0	3950	3987	0.60
JR0805N682F3950FB	6.8	3950	3987	0.50
JR0805N102F3435FA	10	3380	3435	0.72
JR0805N472F3500FB	10	3450	3500	0.65
JR0805N103F3435FA	10	3380	3435	0.44
JR0805N103F3450FB	10	3450	3500	0.40
JR0805N103F3950FB	10	3950	3987	0.44
JR0805N153F3500FB	15	3500	3545	0.32
JR0805N223F3950FB	22	3950	3987	0.30
JR0805N223F4050FB	22	4050	4110	0.31
JR0805N333F4050FB	33	4050	4100	0.24
JR0805N473F4050FB	47	4050	4100	0.20
JR0805N473F4150FB	47	4150	4200	0.20
JR0805N503F4150FB	50	4150	4210	0.18
JR0805N683F4150FB	68	4150	4210	0.16
