MF72-0201 Series

Parameter Inquiry

Part No	Resistance (25℃) (kΩ)	B Constant (25/50℃) (K)	B Constant (25/85℃) (K)	Permissible Operating Current (25℃) (mA)	Dissipation Factor (mW/℃)	Thermal Time Constant (s)	Rated Electric Power (25℃) (mW)	Operating ambient temperature (℃)
JR0201N103F3380FB	10	3380	3435	0.31	1	<3	100	-40~+125
JR0201N103F3435FA	10	3380	3435	0.31
JR0201N103F3950FB	10	3950	3987	0.31
JR0201N223F3380FB	22	3380	3435	0.22
JR0201N223F3950FB	22	3950	3987	0.22
JR0201N473F3950FB	47	3950	3987	0.14
JR0201N473F4050FB	47	4050	4110	0.14
JR0201N473F4100FB	47	4100	4150	0.14
JR0201N683F4150FB	68	4150	4210	0.11
JR0201N683F4250FB	68	4250	4310	0.11
JR0201N104F4150FB	100	4150	4210	0.1
JR0201N104F4250FB	100	4250	4310	0.1
JR0201N224F4250FB	220	4250	4310	0.06
